Description
The CVEN2.5SQM-V9 Midrange Tweeters are interesting and unusual – only 2 inches in size. Their outer diameter is 6 cm. The mounting depth is 3.7 cm.
The cones of the cones are made of cellulose composite, and the caps, like those of the woofers / midrange speakers, are carbon fibre.
Magnetic systems are based on neodymium magnets. Here, too, there is a large axial channel closed with a porous liner – acoustic load.
Additional Information
Specification
Performance Specifications
Vibe CVEN2.5SQM-V9
FS
143.55Hz
Re
4Ω
Sd
13.2025 cm2
Qms
4.86
Qes
1.12
Qts
0.91
Cms
0.2682 mm/N
Mms
4.5833g
Rms
0.85 Ωm
Bl
3.84 Tm
SPL
74.38 dB
VAS
0.0653 L
Zmin
4.17 Ω
L1kHz
0.15mH
L10kHz
0.15mH
Product Data
Physical Specifications: Vibe CVEN2.5SQM-V9
Outer diameter: 60 mm
Mounting depth: 37 mm
File Download
Delivery Information
Next working day delivery if ordered before 12:00, unless item is special order.
Vibe CVEN2.5SQM-V9 CVEN 2.5″ Midrange Drivers
CVEN SQ 56mm carbon cone midrange driver
£599.99
Want it fitted?We can fit anything we sell at our Nottingham workshop.
The CVEN2.5SQM-V9 Midrange Tweeters are interesting and unusual – only 2 inches in size. Their outer diameter is 6 cm. The mounting depth is 3.7 cm.
The cones of the cones are made of cellulose composite, and the caps, like those of the woofers / midrange speakers, are carbon fibre.
Magnetic systems are based on neodymium magnets. Here, too, there is a large axial channel closed with a porous liner – acoustic load.
Performance Specifications
Vibe CVEN2.5SQM-V9
FS
143.55Hz
Re
4Ω
Sd
13.2025 cm2
Qms
4.86
Qes
1.12
Qts
0.91
Cms
0.2682 mm/N
Mms
4.5833g
Rms
0.85 Ωm
Bl
3.84 Tm
SPL
74.38 dB
VAS
0.0653 L
Zmin
4.17 Ω
L1kHz
0.15mH
L10kHz
0.15mH
Physical Specifications
Vibe CVEN2.5SQM-V9
Outer diameter
60 mm
Mounting depth
37 mm
