Description
MATCH UP W8BMW-S
Maximum POWER for BMW sound concepts
The ultra-flat UP W8BMW-S subwoofers are playing extremely dynamically and punchy. Especially the exceptionally rigid fiberglass cone generates maximum sound pressure without distortions.
The BMW-specific baskets and connectors allow fast and easy installation into the original mounting positions of all BMW model ranges with under-seat subwoofers.
Nevertheless these subwoofers are also perfectly qualified for universal applications. Thanks to the very low mounting depth, extremely compact sealed enclosures are no problem at all whereas the oversized 1.7? / 42.5 mm voice coil assures high power handling. With their 1 x 2 Ohms single voice coil the UP W8BMW-S are the perfect replacement for the original subwoofers of the BMW HiFi sound system. Additionally they are the perfect playmate for our MATCH Upgrade amplifier MATCH UP 7BMW and MATCH UP 7DSP.
No matter if these subwoofers are used for a bass upgrade in your BMW or as supplier of low-frequencies in universal concepts, they will definitely add loads of powerful bass for musical enjoyment.
Features
- 2 x 8? BMW upgrade subwoofer
- Fits perfectly into the original mounting positions under the front seats of all BMW model ranges with under-seat subwoofers
- Extremely stiff fiberglass cone for maximum sound pressure
- 1 x 2 Ohms impedance per woofer
- Oversized 42.5 mm / 1.7? voice coil for high power handling
- BMW connection cables for original BMW cable harness are included in delivery
- Perfectly combinable with the MATCH UPGRADE amplifiers MATCH UP 7BMW and UP 7DSP
- Also ideal for universal use in ultra-flat subwoofer constructions
Compatibility
- Suitable for all BMW model ranges with under-seat subwoofers and universal use
- Perfectly combinable with the MATCH UPGRADE amplifiers MATCH UP 7BMW and UP 7DSP
Additional Information
Specification
Performance Specifications
UP W8BMW-S
Power RMS / max
200 / 400 Watts
Impedance
1 x 2 Ω
DC resistance
2.0 Ω
Resonance frequency
49 Hz
Mechanical Q factor
3.80
Electrical Q factor
0.61
Total Q factor
0.53
Compliance
210 µm/N
Equivalent air volume
13.9 L
Force factor
7.1 Tm
Efficiency 1 W / 1 m
90 dB
Cone area
214 cm²
Moving mass
47.4 g
Cone material
Extremely stiff fiberglass cone
Mechanical resistance
3.97 kg/s
Voice coil diameter
42.5 mm
Voice coil winding height
12.5 mm
Max. linear excursion
‘+/- 4.0 mm
Product Data
Physical Specifications: UP W8BMW-S
Outer diameter: 239 mm / 9.41″
Installation diameter: 175 mm / 6.89″
Installation depth: 40 mm / 1.57″
File Download
Delivery Information
Delivery information content here.
Match UP W8BMW-S 8″ Subwoofer for BMW
8″ / 200 mm subwoofers with very low mounting depth for shallow subwoofer designs and under-seat installation in BMW vehicles
Plug connectors for original BMW cable harness are included in delivery
£239.00
MATCH UP W8BMW-S
Maximum POWER for BMW sound concepts
The ultra-flat UP W8BMW-S subwoofers are playing extremely dynamically and punchy. Especially the exceptionally rigid fiberglass cone generates maximum sound pressure without distortions.
The BMW-specific baskets and connectors allow fast and easy installation into the original mounting positions of all BMW model ranges with under-seat subwoofers.
Nevertheless these subwoofers are also perfectly qualified for universal applications. Thanks to the very low mounting depth, extremely compact sealed enclosures are no problem at all whereas the oversized 1.7? / 42.5 mm voice coil assures high power handling. With their 1 x 2 Ohms single voice coil the UP W8BMW-S are the perfect replacement for the original subwoofers of the BMW HiFi sound system. Additionally they are the perfect playmate for our MATCH Upgrade amplifier MATCH UP 7BMW and MATCH UP 7DSP.
No matter if these subwoofers are used for a bass upgrade in your BMW or as supplier of low-frequencies in universal concepts, they will definitely add loads of powerful bass for musical enjoyment.
Features
- 2 x 8? BMW upgrade subwoofer
- Fits perfectly into the original mounting positions under the front seats of all BMW model ranges with under-seat subwoofers
- Extremely stiff fiberglass cone for maximum sound pressure
- 1 x 2 Ohms impedance per woofer
- Oversized 42.5 mm / 1.7? voice coil for high power handling
- BMW connection cables for original BMW cable harness are included in delivery
- Perfectly combinable with the MATCH UPGRADE amplifiers MATCH UP 7BMW and UP 7DSP
- Also ideal for universal use in ultra-flat subwoofer constructions
Compatibility
- Suitable for all BMW model ranges with under-seat subwoofers and universal use
- Perfectly combinable with the MATCH UPGRADE amplifiers MATCH UP 7BMW and UP 7DSP
Performance Specifications
UP W8BMW-S
Power RMS / max
200 / 400 Watts
Impedance
1 x 2 Ω
DC resistance
2.0 Ω
Resonance frequency
49 Hz
Mechanical Q factor
3.80
Electrical Q factor
0.61
Total Q factor
0.53
Compliance
210 µm/N
Equivalent air volume
13.9 L
Force factor
7.1 Tm
Efficiency 1 W / 1 m
90 dB
Cone area
214 cm²
Moving mass
47.4 g
Cone material
Extremely stiff fiberglass cone
Mechanical resistance
3.97 kg/s
Voice coil diameter
42.5 mm
Voice coil winding height
12.5 mm
Max. linear excursion
‘+/- 4.0 mm
Physical Specifications
UP W8BMW-S
Outer diameter
239 mm / 9.41″
Installation diameter
175 mm / 6.89″
Installation depth
40 mm / 1.57″
