Description
Kicker SoloX L7X81 8″ Square Dual Voice Coil 1 Ohm Subwoofer
SoloX L7X is Kicker’s ferrite competition subwoofer: a triple-stacked ferrite motor around a hyper-extended pole piece, a 2.5″ voice coil on a dual-spider suspension, and a double-pressed pulp cone on an ultra-long-throw Santoprene surround, with square-cone tech and Forced-Air Cooling. The 8″ L7X81 has dual 1 Ohm voice coils.
Features
- 8″ competition subwoofer, dual voice coil (DVC), 1 Ohm per coil
- Triple-stacked ferrite magnet motor
- Dual-spider suspension
- Double-pressed pulp cone with long-throw surround
- Forced-Air Cooling
Additional Information
Specification
Performance Specifications
Kicker L7X81
Voice coils
Dual voice coil (DVC), 1 Ohm per coil
Recommended amplifier power RMS
400-800 W
Frequency response
30 Hz – 100 Hz
Vented enclosure tuning frequency
39 Hz
Product Data
Physical Specifications: Kicker L7X81
Subwoofer size: 200 mm / 8″
Magnet diameter: 176 mm / 6-15/16″
Total magnet weight: 6.4 kg / 225 oz
Voice coil diameter: 62.5 mm / 2.5″
Voice coil winding width: 48 mm / 1-7/8″
Top plate thickness: 8 mm / 5/16″
Xmax: 24 mm / 15/16″
Mounting cutout: 186 mm / 7-5/16″
Mounting depth: 201 mm / 7-15/16″
Recommended vented box volume: 25 L / 0.88 cu ft
Port opening: 50 x 230 mm / 2″ x 9″
Port length: 820 mm / 32.25″
File Download
Delivery Information
Next working day delivery if ordered before 12:00, unless item is special order.
Kicker SoloX L7X81 8″ Square Dual Voice Coil 1 Ohm Subwoofer
Kicker SoloX L7X81 8″ Square Dual Voice Coil 1 Ohm Subwoofer, part number KA49L7X81. 8″ competition subwoofer, dual voice coil (DVC), 1 Ohm per coil. Triple-stacked ferrite magnet motor.
£429.95
Want it fitted?We can fit anything we sell at our Nottingham workshop.
Kicker SoloX L7X81 8″ Square Dual Voice Coil 1 Ohm Subwoofer
SoloX L7X is Kicker’s ferrite competition subwoofer: a triple-stacked ferrite motor around a hyper-extended pole piece, a 2.5″ voice coil on a dual-spider suspension, and a double-pressed pulp cone on an ultra-long-throw Santoprene surround, with square-cone tech and Forced-Air Cooling. The 8″ L7X81 has dual 1 Ohm voice coils.
Features
- 8″ competition subwoofer, dual voice coil (DVC), 1 Ohm per coil
- Triple-stacked ferrite magnet motor
- Dual-spider suspension
- Double-pressed pulp cone with long-throw surround
- Forced-Air Cooling
Performance Specifications
Kicker L7X81
Voice coils
Dual voice coil (DVC), 1 Ohm per coil
Recommended amplifier power RMS
400-800 W
Frequency response
30 Hz – 100 Hz
Vented enclosure tuning frequency
39 Hz
Physical Specifications
Kicker L7X81
Subwoofer size
200 mm / 8″
Magnet diameter
176 mm / 6-15/16″
Total magnet weight
6.4 kg / 225 oz
Voice coil diameter
62.5 mm / 2.5″
Voice coil winding width
48 mm / 1-7/8″
Top plate thickness
8 mm / 5/16″
Xmax
24 mm / 15/16″
Mounting cutout
186 mm / 7-5/16″
Mounting depth
201 mm / 7-15/16″
Recommended vented box volume
25 L / 0.88 cu ft
Port opening
50 x 230 mm / 2″ x 9″
Port length
820 mm / 32.25″
Next working day delivery if ordered before 12:00, unless item is special order.
